2-20 PERIODIC MAINTENANCE
BATTERY SOLUTION LEVEL CHECK
The battery solution level should be between the UPPER level
and the LOWER level.
If the level is low, add distilled water only.
#
Once the battery has been initially serviced, NEVER add
diluted sulphuric acid, or you will damage the battery.
Follow the battery manufacture’s instructions for spe-
cific maintenance procedures.
BATTERY SOLUTION SPECIFIC GRAVITY CHECK
Measure the gravity of the battery solution by using the hydrom-
eter.
! 09900-28403: Hydrometer
Battery solution specific gravity: 1.28 at 20 °C
BOLTS AND NUTS
Inspect initially after 20 hours (1 month) and every 100
hours (6 months) thereafter.
Check that all bolts and nuts listed below are tightened to their
specified torque.
ITEM
TIGHTENING TORQUE
N
.
m kg-m lb-ft
Cylinder head cover bolt 10 1.0 7.0
Cylinder head bolt
Power unit mounting bolt / nut
Clamp bracket shaft nut
190 19.0 137.5
Gearcase bolt
Propeller nut
43 4.3 31.0
73 7.3 53.0
23 2.3 16.5
23 2.3 16.5
8 mm
8 mm
50 5.0 36.0
THREAD
DIAMETER
10 mm
6 mm
16 mm
10 mm
22 mm
8 mm 23 2.3
16.5
Intake manifold bolt / nut
Exhaust manifold bolt / nut
Flywheel bolt
10 mm
18 mm
55
55
5.5
5.5
40.0
40.0

Suzuki DF 60 Specifications

General

Cylinders	3
Steering	Remote
Starting System	Electric
Max Power Output	60 hp
Trim Method	Power Trim and Tilt
Engine Type	4-stroke
Displacement	941 cc
Fuel Delivery System	Sequential Multi Point Fuel Injection
Maximum Output	60 HP
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Recommended Fuel	Unleaded gasoline
Exhaust	Through propeller hub
Cooling System	Water-cooled
Warranty	3-year limited warranty
