POWER UNIT 6-3
9. Disconnect the water hose 1 from the oil pan.
10. Disconnect the water hose 2 from the joint.
11. Remove the bolt and the low pressure fuel filter with the
bracket.
12. Disconnect the throttle rod 1.
13. Remove the two bolts 2.
14. Remove the two bolts securing front panel.
15. Disconnect the wires from the CTP switch 1, the IAT sen-
sor 2 and the IAC valve 3.
16. Disconnect the MAP sensor hose 4 from the intake mani-
fold.

Suzuki DF 60 Specifications

General

Cylinders	3
Steering	Remote
Starting System	Electric
Max Power Output	60 hp
Trim Method	Power Trim and Tilt
Engine Type	4-stroke
Displacement	941 cc
Fuel Delivery System	Sequential Multi Point Fuel Injection
Maximum Output	60 HP
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Recommended Fuel	Unleaded gasoline
Exhaust	Through propeller hub
Cooling System	Water-cooled
Warranty	3-year limited warranty
