Suzuki DF 60 Service Manual

POWER UNIT 6-29
4. Remove the three bolts, the thermostat cover, the gasket,
the thermostat and the stopper plates.
5. Remove the two bolts, the water pressure valve cover, the
gasket and the water pressure valve from the exhaust mani-
fold.
6. Remove the ten M10-bolts 1.
7. Remove the ten M8-bolts 2.
8. Remove the crankcase from the cylinder block.
NOTE:
For proper assembly, mark the cylinder number on all conrod
caps using quick dry paint.
9. Remove all conrod cap nuts and conrod caps.
NOTE:
Reassemble each conrod cap to its original position.

Suzuki DF 60 Specifications

General

Cylinders	3
Steering	Remote
Starting System	Electric
Max Power Output	60 hp
Trim Method	Power Trim and Tilt
Engine Type	4-stroke
Displacement	941 cc
Fuel Delivery System	Sequential Multi Point Fuel Injection
Maximum Output	60 HP
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Recommended Fuel	Unleaded gasoline
Exhaust	Through propeller hub
Cooling System	Water-cooled
Warranty	3-year limited warranty
