MID UNIT 7-21
6. Install the springs and the pins to the lower mount cover.
7. Install the lower mount cap to the lower mount cover, then
tighten the screw.
BONDING WIRE
Install the bonding wires to the driveshaft housing, then tighten
the screw.
POWER UNIT
Install the power unit. (See the page 6-11.)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki DF 60 and is the answer not in the manual?

Suzuki DF 60 Specifications

General IconGeneral
Cylinders3
SteeringRemote
Starting SystemElectric
Max Power Output60 hp
Trim MethodPower Trim and Tilt
Engine Type4-stroke
Displacement941 cc
Fuel Delivery SystemSequential Multi Point Fuel Injection
Maximum Output60 HP
Full Throttle Operating Range5, 300 - 6, 300 rpm
Recommended FuelUnleaded gasoline
ExhaustThrough propeller hub
Cooling SystemWater-cooled
Warranty3-year limited warranty
