8-8 POWER TRIM AND TILT
• Inspect the manual release valve for damage.
Replace if necessary.
• Inspect the O-rings for cuts, nicks or tears.
• Inspect the lower shaft and the upper shaft for bent, twist or
other damage.
Replace if necessary.
• Inspect all bushings for excessive wear or other damage.
Replace if necessary.
If bushing fit is loose when installing, replace the bushing.

Suzuki DF 60 Specifications

General

Cylinders	3
Steering	Remote
Starting System	Electric
Max Power Output	60 hp
Trim Method	Power Trim and Tilt
Engine Type	4-stroke
Displacement	941 cc
Fuel Delivery System	Sequential Multi Point Fuel Injection
Maximum Output	60 HP
Full Throttle Operating Range	5, 300 - 6, 300 rpm
Recommended Fuel	Unleaded gasoline
Exhaust	Through propeller hub
Cooling System	Water-cooled
Warranty	3-year limited warranty
