5-26
DRIVE SHAFT BOOTS
FRONT
REAR
Check the drive shaft rubber boots for
damage and grease leak. Ask you
Suzuki dealer if replacement is nec-
essary.
LIGHT BULB REPLACEMENT
The wattage rating of each bulb is
shown in the following chart. When
replacing a burned out bulb, always
use the same wattage rating.
Headlight 12V 35/35W × 2
Auxiliary headlight 12V 35/35W
Brake/Taillight 12V 21/5W
CAUTION
Failure to use a light bulb with the
correct wattage rating can dam-
age your ATV.
The electrical system can over-
load, or the bulb may burn out
sooner.
Use only the light bulbs shown in
the chart as replacement bulbs.
