5-29
BRAKE/TAILLIGHT
Replace the brake/taillight bulb as fol-
lows:
1. Turn the socket counterclockwise
and pull it off.
2. Push the bulb in and turn it to the
left. Remove the bulb.
3. To install a new bulb, push the
bulb in firmly and turn it to the
right while pushing in.
4. Replace the socket.
FUSES
The main fuse is located under the
seat. One 30A spare fuse is located
under the fuse box.
The fuses are located under the seat.
One 10A and one 15A spare fuses
are provided inside the fuse box.
They are designed to open when a
circuit overload exists in individual
electrical system circuits. If any elec-
trical system fails to operate, then the
fuses must be checked.
