DRIVE TRAIN 4-5
 Remove the snap ring.
 Remove the O-ring
1.
 Drive out the bearing from the other side with the special tool.
" 09913-70210: Bearing installer set
NOTE:
If there is no abnormal condition, the bearing removal is not nec-
essary.
#
 Remove the bearing and oil seal with a suitable tool.
NOTE:
If there is no abnormal condition, the bearing/oil seal removal is
not necessary.
#
 Remove the oil seal with a suitable tool.
NOTE:
If there is no abnormal condition, the oil seal removal is not nec-
essary.
#
The removed bearing must be replaced with a new
one.
The removed bearing and oil seal must be replaced
with the new ones.
The removed oil seal must be replaced with a new one.
