10-2 LT-Z250K5 (îš’05-MODEL)
SPECIFICATIONS
DIMENSIONS AND DRY MASS
Overall length...................................................................................... 1 720 mm (67.7 in)
Overall width ....................................................................................... 1 070 mm (42.1 in)
Overall height...................................................................................... 1 090 mm (42.9 in)
Wheelbase.......................................................................................... 1 135 mm (44.7 in)
Front track........................................................................................... 830 mm (32.7 in)
Rear track............................................................................................ 810 mm (31.9 in)
Ground clearance................................................................................ 230 mm (9.1 in)
Seat height.......................................................................................... 810 mm (31.9 in)
Dry mass............................................................................................. 166 kg (365 lbs)
ENGINE
Type..................................................................................................... Four-stroke, air-cooled, OHC
Number of cylinders............................................................................ 1
Bore .................................................................................................... 66.0 mm (2.598 in)
Stroke.................................................................................................. 72.0 mm (2.835 in)
Displacement ...................................................................................... 246 cm
3
(15.0 cu. in)
Compression ratio............................................................................... 9.2: 1
Carburetor........................................................................................... MIKUNI BSR29, single
Air cleaner........................................................................................... Polyurethane foam element
Starter system..................................................................................... Electric
Lubrication system.............................................................................. Wet sump
Idle speed ........................................................................................... 1 500 – 100 r/min
DRIVE TRAIN
Clutch.................................................................................................. Wet multi-plate, automatic, centrifugal type
Transmission ....................................................................................... 5-forward and 1-reverse
Gearshift pattern, forward................................................................. All up, foot lever operated
reverse................................................................. Foot/hand operated
Primary reduction ratio........................................................................ 3.047 (64/21)
Secondary reduction ratio................................................................... 1.133 (17/15)
Gear ratios, Low .............................................................................. 3.083 (37/12)
2nd............................................................................... 1.933 (29/15)
3rd................................................................................ 1.388 (25/18)
4th................................................................................ 1.095 (23/21)
Top ............................................................................... 0.913 (21/23)
Reverse........................................................................ 2.833 (34/12)
Final reduction ratio............................................................................. 3.200 (32/10)
CHASSIS
Front suspension................................................................................. Independent, double wishbone, coil spring, oil damped
Rear suspension................................................................................. Swingarm type, coil spring, oil damped
Front wheel travel................................................................................ 160 mm (6.3 in)
Rear wheel travel ................................................................................ 170 mm (6.7 in)
Caster ................................................................................................. 7îš° 40îš’.....................1G
Trail...................................................................................................... 33 mm (1.30 in).....1G
Toe-in .................................................................................................. 5 mm (0.20 in).......1G
Steering angle..................................................................................... 45îš°
Turning radius ..................................................................................... 2.7 m (8.9 ft)
Front brake.......................................................................................... Disc brake, twin
Rear brake .......................................................................................... Drum brake
Front tire size ...................................................................................... AT22  7-10 , tubeless
Rear tire size....................................................................................... AT20  10-9 , tubeless
ELECTRICAL
Ignition type......................................................................................... Electronic ignition (CDI)
Ignition timing...................................................................................... 5îš° B.T.D.C. at 1 500 rpm
Spark plug........................................................................................... NGK DR7EA or DENSO X22ESR-U
Battery................................................................................................. 12 V 28.8 kC (8 Ah)/10 HR
Generator............................................................................................ Three-phase A.C. generator
Main fuse ............................................................................................ 20/15 A
Headlight............................................................................................. 12 V 40/40 W
Brake light/Taillight .............................................................................. 12 V 21/5 W
Neutral indicator light .......................................................................... 12 V 3 W
Reverse indicator light......................................................................... 12 V 3 W
CAPACITIES
Fuel tank, including reserve.............................................................. 10.6 L (2.8/2.3 US/Imp gal)
reserve............................................................................. 2.6 L (0.7/0.6 US/Imp gal)
Engine oil, oil change......................................................................... 2 200 ml (2.3/1.9 US/Imp qt)
filter change ..................................................................... 2 300 ml (2.4/2.0 US/Imp qt)
overhaul ........................................................................... 2 500 ml (2.6/2.2 US/Imp qt)
Final gear oil change........................................................................... 190 ml (6.4/6.7 US/Imp oz)
