d.1.1Wherearepictogramsplacedontheunits
Example(Symbolsanddescripti onsoffunctionsforfastidentification)
Position Description
S
y
mbol
1
TheCElabelandtheuniqueproductionnumberofthismachine
2
Machinecard

3
Damper‐supplyair
4
Filter‐supplyair

5
Fan‐supplyair
6 Heatingbattery‐supplyair
7
Fan‐extractair
8
Rotaryheatexchanger
9
Filter–extractair

10
Damper–extractair
11A
3labels.OnelabelwithFlowchart,onelabelwithterminalplanforexternal
componentsandonelabellisting dataaboutthecabinet.Thelabelsareplaced
behindinspectiondoors,ifthecabinetwith controlsystemisinsidetheunit.

11B
3labels.OnelabelwithFlowchart,onelabelwithterminalplanforexternal
componentsandonelabellisting dataaboutthecabinet.Thelabelsareplacedon
thecoverofthecabinet,ifthecabinetwithcontrolsystemisplacedonthetopofor
onthefrontofthe
unit.





