i.Instructionsforunloadingonthesiteaswellasinstallationand
connection
i.1.Unloadingonthesite
Theairhandlingunit–AHU‐isdeliveredasonesectionorinseveralsections,whicharetobeassembled
onsite.TheAHUisdeliveredontransportpallets,legsoronabaseframe.Loadingandunloadingaswellas
transportonthesiteispossiblebyfork‐lifttruck
orbycraneusingsuitableliftingstraps.

i.1.1Unloadingbyfork‐lifttruck
TheforksofthetruckmustbesufficientlylongtoavoidanydamagetotheAHUunderside.

i.1.2Unloadingbycrane
AHUdeliveredontransportpalletmustbeliftedbystrapsasshownintheillustration.

AHUdeliveredwithlegsmustbeliftedbystrapssecuredtothelegsasshownintheillustration.



i.1.3Transportofunitwithoutbaseframeonthesite
Unitswithoutbaseframearealwaysdeliveredinsectionswitheachsectiononapallet.Sectionscanbe
transportedonthesitebyhandmanualforklifts.


i.1.4Liftingaunitwithstraps
Useanappropriateliftingbeamwithasufficientspantoavoidthatthestrapstouchanddamagethedrip
noseprofilesandtheinspectionsidewithhandles,pipesandaccessories–forexamplemanometers,
cabinets,tabsformeasuringthepressure.



