20



d.2.5Exampleoflabelplacedonorwiththecabinet–Terminalplanforexternal

components



d.3Handterminal(optionalforDVunits–alwaysstandardforTIMEunits)

Thehandterminalisdeliv eredinacardboardboxcontainingtheotherexternalcomponents.This

cardboardboxisusually,butnotalways,placedinthesectionwiththesupplyairfan.TheOperator’sGuide

forthehandterminalistheannex17attachedtothis–UserManual.



Important!AllLEDsonthehandterminalmustbeoffbeforestartupoftheunit.



1. ALARM:Pressforalarmlist

2. AlarmLED–redlightforalarm

3. LEDindicatingchangeofparameters

4. OK/ENTER

5. Pressforclear

6. Pressformoveofcurserinmenu
