32
Unit Motor Fuse
Minimum
Fuse
Maximum
Maximum
Short‐circuitcurrent
TIME10 2*0.94kW
2*0.99kW
10A 16A 16kA
TIME15 2*0.99kW
2*1.7kW
10A
13A
25A 16kA
TIME20 2*1.7kW
2*3.0kW
13A 25A 16kA
TIME25 2*3.0kW
2*2.73kW
13A
13A
25A 16kA
TIME30 2*2.73kW
2*5.18kW
20A 32A 16kA
TIME40 2*5.18kW
2*4.7kW
20A
20A
32A 16kA
i.3.3.2NecessarymainspowersupplyforDVunitswithcabinet/controlsystem
Necessarymainspowersupplyisprintedontheuniquemachinecardplacedonthefrontofeveryunit(see
exampleofamachinecardinsectiond.2.1).
i.3.3.3Necessaryovervoltageprotectiondevice,thatleadslightningovervoltagetoanearthlead
ona
safeway.
TheInstallerandusermustbeawareofthefactthatlightningstrikesmakeariskthatrequiresinstallation
ofovervoltageprotectiondevicestoleadtheli ghtningovervoltagetoanearthleadinasafeway.
Installerandusermusttakecareofthisaccordingto
localstatutoryrequirements.
i.3.4Electricalconnectionofcomponentsandfunctions
Externalcomponentsandfunctionsaredeliveredaccordingtotheorderconfirmation.Cablenumber’sare
writtenonthecables,onthelabelwithterminalplanonorwiththecabinet–seesectiond.2.5andinthe
wiringdiagrams–annex16.
i.3.4.1ConnectionoftheSystemairControlPaneltotheCorrigo
E28controller–softwareversion3.3
TheSCPpanel–partnumberS‐208997forsoftwareversion3.3‐isprovidedwith10metresofcableanda
socketforconnectionwiththecontrollerinsidethecabinet.Thecableisnotpulledthroughthecableentry
inthecabinet,sodemount
thecableatthebackoftheSyste mairControlPanel‐pullthecablethroughthe
cableentryinthecabinet‐adjustthelengthofthecableandremountthecableinthepanel,oraddmore
cable–upto100mofcablebetweentheSystemairControlPanelandthe
controllerispossible.Placethe
SystemairControlPanelontheoutersideoftheunitoronawall.
