Geniox Air Handling Unit - User Manual | 3060386
C General descriptions, dangers and warnings
Genioxairhandlingunitsareorderspecicmachinesavailableinthousandsofdifferentcongurations.Onlyafewexamplesofmachine
congurationsaredescribedbelow.Theairhandlingunitsareintendedforthetransportandtreatmentofairbetween-40°Fand
+110°F.
The units are exclusively for comfort ventilation.
Maintenance of the units must be carried out by skilled technicians.
On the drawing below, a right hand unit is shown because the inspection doors are mounted on the right hand side of the unit when
looked in direction of SUPPLYairow.Theunitbelowiswithenergyrecoverywheel.
Position Description Symbol
A Connection, supply air (to the rooms)
B Connection, exhaust air
C Connection, outdoor air
D Connection, return air (from the rooms)
C.1 Overview via pictograms on the inspection side of the unit
C.1.1 Where are pictograms placed on the units
Example(Pictogramsandlabelswithdescriptionsoffunctionsforfastidentication)
Position Description Symbol
1 At each section a label with production number of this air handling unit
2 Machine card
4 | General description, danger and warnings
