3060386 | Geniox Air Handling Unit - User Manual
Position Description Symbol
3 Damper - supply air
4 Filter - supply air
5 Fan- supply air
6 Heating coil - supply air
7 Fan - return air
8 Energy recovery wheel
9 Filter – return air
10 Damper – return air
11 Integrated control system in a cabinet behind this inspection door.
C.1.2 Geniox nameplate
Weight of the section. Production number of the unit.
Number of the section in the unit.
Product name in this example Geniox 25, where 25 indicates the size of
the unit.
Geniox 25
Prod. No: 00046016
Weight: 2000 lbs
Section: 3/4
General desription danger and warnings | 5
Systemair Inc.
8 Rouse St. Tillsonburg, ON Canada N4G
5W8
www.systemair.net
Geniox 25 – Customer Information
Agency
Logo here
Unit Voltage XXX V/ X Ph/ 60 Hz
Unit FLA --A
Unit MCA --A
Maximum Overcurrent Protective Device --A
Short-Circuit Current 5kA rms symmetrical, XXXV max.
Model No: See Nomenclature Table
Serial No: 1234567890-YDDYM-001
Electric Heat
Power -----kW -----A
Type SCR
Fans
Supply Re turn ERW
Airflow ----- cfm ----- cfm
Power ----- HP ----- HP -----HP
FLA ----- A ----- A -----A
Max. Inlet Water Temp. 200 F (93 C)
Max. Outlet Air Temp. 165 F (74 C)
Ref. Design Pressures Low/High 236/600 psig Ref. R410A
Max. External Static Pressure -- in wc (-- Pa) -- in wc (-- Pa)
Min. Working Space Clearances Service Access 36 in(1 m)
Min. Clearances to Combustibles All Sides Zero
Indoor use / Utilisation en intérieur
CSA C22.2 No. 236:2015/UL 1995:2015 Heating and Cooling Equipment
Rev 200723ID Mfg. 467
Systemair Inc.
8 Rouse St. Tillsonburg, ON Canada N4G
5W8
www.systemair.net
Geniox 25 – Customer Information
Agency
Logo here
Unit Voltage XXX V/ X Ph/ 60 Hz
Unit
FLA --A
Unit
MCA --A
Max
imum Overcurrent Protective Device --A
Short
-Circuit Current 5kA rms symmetrical, XXXV max.
Model No: See Nomenclature Table
Serial No: 1234567890-YDDYM-001
Electric Heat
Power -----kW -----A
Type SCR
Fans
Supply Re turn ERW
Airflow ----- cfm ----- cfm
Power ----- HP ----- HP -----HP
FLA ----- A ----- A -----A
Max
. Inlet Water Temp. 200 F (93 C)
Max
. Outlet Air Temp. 165 F (74 C)
Ref.
Design Pressures Low/High 236/600 psig Ref. R410A
Max
. External Static Pressure -- in wc (-- Pa) -- in wc (-- Pa)
Min
. Working Space Clearances Service Access 36 in(1 m)
Min
. Clearances to Combustibles All Sides Zero
Outdoor
use / Utilisation en extérieur
CSA C22.2 No. 236:2015/UL 1995:2015 Heating and Cooling Equipment
Rev 200723OD Mfg. 467
