Geniox Air Handling Unit - User Manual | 3060386
C.1.3 Pictogram on a door for a fan in a Geniox unit
Exampleofthepictogramwiththesymbolforthefunction-fan.Directionofarrowindicatesthedirectionoftheairow.
C.1.4 Pictograms for all available functions in the units
Id Description Symbol
GenioxA Vertical Damper
GenioxB Horizontal Damper
GenioxM Damper for mixing
GenioxP Damper for mixing
GenioxG Panellter
GenioxF Baglter
GenioxC Energy recovery wheel
GenioxQ Plateheatexchanger(crossow)
GenioxH Heating coil
GenioxK Cooling coil
GenioxE Plug fan
GenioxD Silencer
6 | General description, danger and warnings
C.1.5 Safety labels and warnings
GENERAL SAFETY GUIDELINES
IMPORTANT: READ BEFORE PROCEEDING!
During installation, operation and maintenance of the Geniox Air Handling units individuals may be exposed to certain components or
conditions including but not limited to: heavy objects, refrigerants, materials under pressure, rotating components, and both high and
low voltage.
