Note:

SpecialsizesofltersandMERVratingsareavailablefromCaml.

M.4.1 Bag lters

Turntheunitoffandwaitfor2minutesuntilunitcompletelystops.Usedlterscanbepulledout.Storetheusedltersimmediatelyin

plastic bags to avoid polluting the environment with dust particulates. Geniox units in the sizes 15 – 25 are provided with a very corro-

sive-resistantandreliablesystem,whereltersareslidintotheunitsinalowerandupperdurableU-proleofplastic/rubber.Checkthe

upperandlowerU-prolefordamageandchecktheverticalrubberproleonthebackwallaswellastherubberproleontheinspec-

tiondoorfordamage.Thenewlterbagsmustbepushedcarefullyintotheunitinordertoensurethattheyaresealedproperly.The

ltersmusthaveverticalbags.

BagltersareavailableinMERV9and14rating.OtherMERVratingscanalsobeordered.Bagltersare15inchdeep.

PanelltersareavailableinMERV8and13ratings.OtherMERVratingscanalsobeordered.

2inchdeeppanelltersareavailableasastandardoption.4inchdeeppanelcanalsobeordered.

ONE self-adhesive foam strip must be placed on the vertical

frameofEACHltertoavoidmajorairleakagethroughthe

verticalopeningbetween2lters.Pleasenote–onlyONEself-

adhesive foam strip must be placed on the vertical frame of EACH

lter–Pleaseestablishthepracticalrulethattheself-adhesive

foam strip is placed on the vertical side that is visible from the

inspection side. These very important self-adhesive foam strips

areusuallynotdeliveredbythesuppliersoflters.Thecustomer

must order the self-adhesive foam strip from a supplier of foam

strips. Width of the foam strip is about 9/16” (15 mm) and

thickness of foam strip must be exactly 5/16” (8 mm). If the

thickness of the foam strip is less than 5/16” (8 mm), there will

beagapforleakagebetweenthelters.Ifthefoamstripismore

than5/16”(8mm)therowofltersintheU-prolewillbetoo

wide making it impossible to close the inspection door. Note! The

staff must have the self-adhesive foam strips available when

they go to the air handling unit. Without those self-adhesive

foam strips, any change of lters is impossible.

Remove the protection from the self-adhesive side of the strip.

38 | Adjustment and maintenance operations
