7-9
SPECIFICATIONS
LIFTING CAPACITIES
Rated lift capacity chart
• The loads in the charts do not exceed 87%
of hydraulic lift capacity or 75% of tipping
load.
•
Figures marked with an asterisk (*) are
hydraulically-limited capacities.
•
The mass of slings and any other lifting
devices shall be deducted from the rated
load to determine the net load that may be
lifted.
•
The load point is the bucket hinge pin, and
the bucket posture is with the standard
bucket completely retracted under the arm.
• Unit: daN (lbs)
Load hooking system
A load hooking system must be pr
ovided
with the following capabilities.
1.
A system which can withstand twice the
rated lift capacity no matter at what
position the load is applied.
2.
A system that poses no risk of the lifted
load falling from the hooking device. For
example, equipped with a hook slippage
prevention device.
3. A system that poses no risk of the hooking
system slipping from the hoe attachment.
LIFTING CAPACITIES
• Do not attempt to lift or hold any load
that is greater than these rated values at
their specified load radii and height.
• The rated lift capacities are based on
the machine being level and situated on
a firm supporting surface. For safe
lifting, the operator is expected to make
due allowance for the particular job
conditions such as soft or uneven
ground, non-level condition, side loads,
hazardous conditions, experience of
personnel, etc. The operator and other
personnel should fully acquaint
themselves with the operator’s manual
furnished by the manufacturer before
operating this machine. When operating
the machine, the safety rules of the
equipment must also be followed.
• Do not travel while lifting a load; It is
very dangerous.
