TECO JSDAP Series Simplified Manual

7
dn-08 Display
Drive Model
JSDAP
Motor Model
Motor Standards
Encoder
Specification
Cn030 Setting Watt(KW) Speed(rpm)
H1511
50A3
JSMA-PMA15AB
1.5
1000
2500
H1512 JSMA-PMA15AH 8192
H1515 JSMA-PMA15A5 15 bit(ABS)
H1517 JSMA-PMA15A7 17 bit
H151A JSMA-PMA15AA 17 bit(ABS)
H1521 JSMA-PMB15AB
2000
2500
H1522 JSMA-PMB15AH 8192
H1525 JSMA-PMB15A5 15 bit(ABS)
H1527 JSMA-PMB15A7 17 bit
H152A JSMA-PMB15AA 17 bit(ABS)
H1531 JSMA-PMC15AB
3000
2500
H1532 JSMA-PMC15A5H 8192
H1535 JSMA-PMC15A5 15 bit(ABS)
H1537 JSMA-PMC15A7 17 bit
H153A JSMA-PMC15AA 17 bit(ABS)
H1541 JSMA-PMB20AB
2.0
2000
2500
H1542 JSMA-PMB20AH 8192
H1545 JSMA-PMB20A5 15 bit(ABS)
H1547 JSMA-PMB20A7 17 bit
H154A JSMA-PMB20AA 17 bit(ABS)
H1551 JSMA-PMC20AB
3000
2500
H1552 JSMA-PMC20AH 8192
H1555 JSMA-PMC20A5 15 bit(ABS)
H1557 JSMA-PMC20A7 17 bit
H155A JSMA-PMC20AA 17 bit(ABS)
