AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 17
Introduction
All specifications are guaranteed unless labeled “typical.” Typical specifications are provided for your
convenience, but are not guaranteed.
All specifications apply to the arbitrary function generator unless noted otherwise. These
specifications are valid under the following conditions:
 The instrument must be calibrated or adjusted at an ambient temperature between 20 °C and
30 °C.
 The instrument must be operating at an ambient temperature between 0 °C and 50 °C.
 The instrument must be warmed up for at least 20 minutes.
 The instrument must be in an environment where the temperature, altitude, and humidity
levels are within the operating limits described in these specifications.
NOTE. If you are using a two-channel instrument for differential analog output and one connector is used
as single-ended output, the other connector must be terminated with a 50 Ω connector.
Electrical specifications
The following tables describe the electrical specifications for the AFG31000 Series.
Operating mode
Table 3: Operating mode specifications
Characteristic Description
Run mode
Continuous, Modulation, Sweep, and Burst
Burst count
1 to 1,000,000 cycles or infinite
Internal trigger rate
1 µs to 500 s
