Specifications
20 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
Lead delay (pulse)
Table 7: Lead delay specifications
Range
Continuous mode 0 ps to period
Triggered/Gated Burst mode
0 ps to period – [pulse width + 0.8 × (leading edge
time + trailing edge time)]
Skew
Table 8: Skew specifications for 2-channel model
Pulse function
Frequency 1MHz
1V
pp
Amplitude
Table 9: Amplitude specifications
Range
6
AFG31021,
AFG31022,
AFG31051,
1 mV
pp
to 10 V
pp
2 mV
pp
to 20 V
pp
(into open circuit load)
AFG31101,
AFG31102
1 mV
pp
to 10 V
pp
2 mV
pp
to 20 V
pp
(into open circuit load)
Sine wave at >60 MHz to 80 MHz:
1 mV
pp
to 8 V
pp
into 50 Ω
2 mV
pp
to 16 V
pp
(into open circuit load)
Sine wave at >80 MHz to 100 MHz:
1 mV
pp
to 6 V
pp
into 50 Ω
2 mV
pp
to 12 V
pp
(into open circuit load)
Square/pulse at >40 MHz to 80 MHz:
1 mV
pp
to 5 V
pp
into 50 Ω
2 mV
pp
to 10 V
pp
(into open circuit load)
AFG31151,
AFG31152,
AFG31251,
1 mV
pp
to 5 V
pp
2 mV
pp
to 10 V
pp
(into open circuit load)
6
AFG31251, AFG31252 at frequency >200 MHz to 250 MHz: 1 mVpp to 4 Vpp into 50 Ω, 2 mVpp to 8 Vpp into
opencircuit load.
