Performance verification
AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference 35
Self-test error codes
If the self-tests detect a malfunction, the AFG31000 Series displays [name of the test] failed!
and the error code. The following table lists the error codes with a description of the error and
modules related to the error.
Table 30: Output diagnostics error codes
Error code Description
CH1 internal offset failure
CH2 internal offset failure
CH1 output offset failure
CH2 output offset failure
2305 CH1 output gain failure
2306 CH2 output gain failure
CH1 x12 dB attenuator failure
CH2 x12 dB attenuator failure
CH1 x20 dB K13 attenuator failure
CH2 x20 dB K23 attenuator failure
2405 CH1 x20 dB K14 attenuator failure
2406 CH2 x20 dB K24 attenuator failure
2407 CH1 x14 dB/20 dB K15 attenuator failure
(14 dB for AFG31151, AFG31152, AFG31251, AFG31252; 20 dB for AFG31021,
AFG31022, AFG31051, AFG31052, AFG31101, AFG31102)
2408 CH2 x14 dB/20 dB K25 attenuator failure
2409 CH1 x20 dB K18 attenuator failure
2410 CH2 x20 dB K28 attenuator failure
2502 Ch2 ASIC failure
2503 Ch1 ADC failure
2504 Ch2 ADC failure
