Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Test records
58 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
AFG31101 and AFG31102 test record
Test information
Instrument serial number:
Certificate number:
Temperature: Relative humidity %:
Date of calibration: Technician:
Frequency test record
Frequency Minimum Test result Maximum
Sine at 1.000000 MHz
0.9999984MHz
1.0000016MHz
Pulse at 1.000000 MHz 0.9999984MHz 1.0000016MHz
Amplitude test record:CH1
Calibration factor(CF)=2/(1+50Ω/MeasurementΩ)=
Amplitude Minimum Test result Maximum
3.000mV
rms
at 1.00 kHz (3.000×CF-0.384) mV
rms
(3.000×CF+0.384) mV
rms
30.000mV
rms
at 1.00 kHz (30.000×CF-0.654) mV
rms
(30.000×CF+0.654) mV
rms
300.000mV
rms
at 1.00 kHz
(300.000×CF-3.354) mV
rms
(300.000×CF+3.354) mV
rms
800.000mV
rms
at 1.00 kHz
(800.000×CF-8.354) mV
rms
(800.000×CF+8.354) mV
rms
1.500V
rms
at 1.00 kHz
(1.500×CF-0.015) V
rms
(1.500×CF+0.015) V
rms
2.000V
rms
at 1.00 kHz (2.000×CF-0.020) V
rms
(2.000×CF+0.020) V
rms
2.500V
rms
at 1.00 kHz
(2.500×CF-0.025) V
rms
(2.500×CF+0.025) V
rms
3.500V
rms
at 1.00 kHz
(3.500×CF-0.035) V
rms
(3.500×CF+0.035) V
rms
Amplitude test record:CH2
Calibration factor(CF)=2/(1+50Ω/MeasurementΩ)=
Amplitude Minimum Test result Maximum
3.000mV
rms
at 1.00 kHz
(3.000×CF-0.384) mV
rms
(3.000×CF+0.384) mV
rms
30.000mV
rms
at 1.00 kHz (30.000×CF-0.654) mV
rms
(30.000×CF+0.654) mV
rms
300.000mV
rms
at 1.00 kHz
(300.000×CF-3.354) mV
rms
(300.000×CF+3.354) mV
rms
800.000mV
rms
at 1.00 kHz
(800.000×CF-8.354) mV
rms
(800.000×CF+8.354) mV
rms
1.500V
rms
at 1.00 kHz
(1.500×CF-0.015) V
rms
(1.500×CF+0.015) V
rms
2.000V
rms
at 1.00 kHz (2.000×CF-0.020) V
rms
(2.000×CF+0.020) V
rms
2.500V
rms
at 1.00 kHz
(2.500×CF-0.025) V
rms
(2.500×CF+0.025) V
rms
3.500V
rms
at 1.00 kHz
(3.500×CF-0.035) V
rms
(3.500×CF+0.035) V
rms
