Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Performance verification
38 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
Equipment required
The following table lists the equipment necessary to complete the performance tests.
Table 33: Test equipment for performance tests
Description Minimum requirements Recommended
equipment
Purpose
Digital multimeter (DMM)
AC volts, true RMS
AC-coupled accuracy:
±0.1% to 1 kHz
DC volts accuracy:
50 ppm, resolution
100 μV
Resistance Accuracy:
±0.05 Ω
Keithley Model 2002
Measures voltage. Used
in multiple procedures.
Power meter 100 kHz to 250 MHz
1 μW to 100 mW
(–30 dBm to +20 dBm)
Accuracy: 0.02 dB
Resolution: 0.01 dB
R&S NRVS Measures voltage. Used
in multiple procedures.
Power head
100 kHz to 250 MHz
1 μW to 100 mW
(–30 dBm to 20 dBm)
R&S NRV-Z5
Measures voltage. Used
in multiple procedures.
Frequency counter
Accuracy: 0.01 ppm
Phase measurement
Tektronix FCA3100
Checks clock frequency.
Oscilloscope
1 GHz bandwidth, 50 Ω
input termination
Tektronix TDS5104B
Checks output signals.
Used in multiple
procedures.
Spectrum analyzer 1 GHz bandwidth, 50 Ω
input termination
Tektronix RSA3303A Checks output signals.
Harmonics spurious.
BNC coaxial cable
50 Ω, male-to-male BNC
connector, 91 cm
Tektronix part number
012-0482-00
Interconnects signals.
BNC terminator
50 Ω, ±1 Ω , 2 W, DC to
1 GHz, BNC
Tektronix part number
011-0049-02
Interconnects signals.
Attenuator 50 Ω , x10, BNC
Tektronix part number
011-0059-03
Interconnects signals.
Adapter Dual-Banana
Plug
BNC (female) to dual
banana
Tektronix part number
103-0090-00
Signal interconnection to
a DMM.
Adapter BNC(female)-N(male) Tektronix part number
103-0045-00
Signal interconnection to
a spectrum analyzer.
