Tektronix AFG31000 Series Specification And Performance Verification Technical Reference

Specifications
28 AFG31000 Series Arbitrary Function Generator Specification and Performance Verification Technical Reference
Rear panel
Table 25: Rear-panel input and output specifications
Characteristic
Description
External modulation input
Input range -1.0 V to 1 V full scale (except FSK), 3.3 V logic level
Input impedance
5.2 kΩ
Frequency range
AM, FM, PM, FSK, PWM: DC to 125 kHz (sampling rate: 1 MS/s)
Jitter (RMS), range
Trigger to signal output (signal output
with external trigger input in burst
mode)
100 ps
External reference output
AFG31101, AFG31102, AFG31151, AFG31152, AFG31251, AFG31252
Impedance
50 Ω, AC coupled
Amplitude, typical
1.2 V
pp
into 50 Ω
External reference input
Impedance 1 kΩ
Required input
voltage swing
100 mV
pp
to 5 V
pp
Lock range
10 MHz ± 35 kHz
CH1 additional input AFG31101, AFG31102, AFG31151, AFG31152, AFG31251, AFG31252
Impedance 50 Ω
Input range –1 V to 1 V (DC + peak AC)
Bandwidth
DC to 10 MHz (–3 dB) at 1 V
pp
General specifications
The following topics describe the general specifications of the AFG31000 Series.
Power
Table 26: Power specifications
Characteristic Description
Source voltage and
frequency
100 V to 240 V, 47 Hz to 63 Hz
115 V, 360 to 440 Hz
Power consumption Less than 120 W
Surge current
30 A peak (25° C) for ≤ 5 line cycles, after product has been turned off for at
least 30 s
