Output characteristics
Table 12: Sine wave output specifications
(at 1.0 V
pp
amplitude,
relative to
1 kHz)
<5 MHz: ±0.2 dB
≥5 MHz to ≤25 MHz: ±0.3 dB
AC flatness test
(on page 45)
AFG31051, AFG31052 <5 MHz: ±0.2 dB
≥5 MHz to ≤50 MHz: ±0.3 dB
<5 MHz: ±0.2 dB
≥5 MHz to ≤100 MHz: ±0.3 dB
≥5 MHz to <25 MHz: ±0.3 dB
≥25 MHz to <100 MHz: ±0.5 dB
≥100 MHz to ≤150 MHz: ±1.0 dB
AFG31251, AFG31252
<5 MHz: ±0.2 dB
≥5 MHz to <25 MHz: ±0.3 dB
≥25 MHz to <100 MHz: ±0.5 dB
≥100 MHz to <200 MHz: ±1.0 dB
≥200 MHz to ≤250 MHz: ±2.0 dB
distortion
(at 1.0 Vpp
amplitude)
≥20kHz to <1MHz: <-60dBc
≥1MHz to <5MHz: <-50dBc
≥20kHz to <1MHz: <-60dBc
≥1MHz to <5MHz: <-50dBc
≥5MHz to ≤50MHz :<-37dBc
AFG31101, AFG31102 10Hz to <20KHz: <-70dBc
≥20kHz to <1MHz: <-60dBc
≥1MHz to <5MHz: <-50dBc
≥5MHz to ≤100MHz: <-37dBc
AFG31151, AFG31152 10Hz to <1MHz: <-60dBc
≥1MHz to <5MHz: <-50dBc
≥5MHz to <25MHz: <-37dBc
≥25MHz to ≤150MHz: <-30dBc
≥1MHz to <5MHz: <-50dBc
≥5MHz to <25MHz: <-37dBc
≥25MHz to ≤250MHz: <-30dBc
Spurious
(nonharmonic)
(at 1.0 V
pp
amplitude)
10 Hz to <1 MHz: <–60 dBc
≥1 MHz to ≤25 MHz: <–50 dBc
AFG31051, AFG31052 10 Hz to <1 MHz: <–60 dBc
≥1 MHz to <25 MHz: <–50 dBc
≥25 MHz to ≤50 MHz: <–50 dBc
AFG31101, AFG31102
10 Hz to <1 MHz: <–60 dBc
≥1 MHz to <25 MHz: <–50 dBc
≥25 MHz to ≤100 MHz: <–50 dBc
9
Exclude harmonics and channel crosstalk.
