Probe controls window
From the Vertical menu, select Probe Controls.
Overview
Use the controls in these windows to operate a probe while taking measurements.
The type of probe you connect determines the available controls. For example, the window below contains controls for a
Tektronix current probe.
The following window contains controls for Tektronix TAP1500/TAP2500 type probes.
This window contains controls for Tektronix TriMode probes.
This window contains controls for Tektronix logic probes.
This window contains controls for Tektronix generic probes.
Vertical setups
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 509
