Tektronix MDO3000 Series Technical Reference

Specifications
Table 16: AFG Characteristics (cont.)
DC offset range
±2.5 V into Hi-Z
±1.25 V into 50 
DC offset resolution 500 V(50)
1 mV (HiZ)
DC offset accuracy
±[ (1.5% of offset setting) + 1 mV ]
Add 3 m V of uncertainty per 10 °C change from 25 °C ambient
Digital Voltmeter/Counter
Table 17: Digital voltmeter/counter
Characteristic
Description
Measurement types
AC+DC
rms
,DC
rms
,AC
rms
, frequency count
Voltage resolution 4 digits
Voltag
e accuracy
DC: ±( 2 mV + [ ((( 4 * (Vertical Scale Voltage)) / ( Absolute Input Voltage) ) + 1 )% of
Absolute Input Voltage ] + (0.5% of Absolute Offset Voltage))
DC example: an input channel set up w ith +2 V offset and 1 V/div measuring a –5 V
signal would have ±( 2 mV + [((( 4 * 1 ) / 5 ) + 1 )% of 5 V] + [0.5% of 2 V] ) = ±(
2 mV + [1.8% of 5 V] + [0.5% of 2 V] ) = ±( 2 mV + 90 mV + 10 mV ) = ±102 mV.
This is roughly ±2% of the input voltage.
AC:±2%(40Hzto1kHz)
AC (typical): ±2% (20 Hz to 10 kHz)
For AC m easurements, the input channel vertical settings must allow the V
pp
input
signal to cover between 4 and 8 divisions.
Frequency resolution 5 digits
Fre
quency accuracy
±(10 µHz/Hz + 1 count)
Frequency counter source Any analog input channel.
Frequency c ounter maximum input
frequency
100
MHz for 100 MHz models
150 MHz for all other models
Trigger Sensitivity limits must be observed for reliable frequency measurements.
32 MDO3000 Series Specifications and Performance Verification
