Commands Listed in Alphabetical Order
Syntax
MEASUrement:I
NDICators:NUMHORZ?
Examples
MEASUREMENT:INDICATORS:NUMHORZ? might return
MEASUREMENT:INDICATORS:NUMHORZ 2 indicating there are currently
2 horizontal lines drawn on the graticule. The indicators show where the
measurement specified by MEASUrement:INDICators:STATE is being
performed.
MEASUrement:INDICators:NUMVERT? (Query Only)
Returns the number of vertical measurement indicators currently being displayed.
Group
Measurement
Syntax
MEASUrement:INDICators:NUMVERT?
Examples
MEASUREMENT:INDICATORS:NUMVERT? might return
MEASUREMENT:INDICATORS:NUMVERT 2 indicating there are currently 2
vertical lines drawn on the graticule. The indicators show where the measurement
specified by MEASUrement:INDICators:STATE is being performed.
MEASUrement:INDICators:STATE
This command specifies the state of visible measurement indicators.
Group
Measurement
Syntax
MEASUrement:INDICators:STATE {OFF|MEAS<x>}
MEASUrement:INDICators:STATE?
Arguments
OFF turns the visible measurement indicators off.
MEAS<x> displays the visible measurement indicators for measurement <x>,
where <x> can be 1 through 8.
NOTE. Theremustbeanactivemeasurementbefore you can activate an indicator
for a specified measur ement.
2-432 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
