Tektronix TBS1072B User Manual

Utility
Push the Utility button to display the Utility Menu.
EDU-models
Options Settings Comments
Display Type (Vectors, Dots),
Persist (1 sec, 2 sec.
5 sec. Infinite, Off),
Format (YT, XY),
Backlight (1% to 100%)
Language English, French,
German, Italian,
Spanish, Japanese,
Portuguese, Simplified
Chinese, Traditional
Chinese, Korean,
Russian
Selects the display language of the oscilloscope
Do Self Cal Performs a self calibration
Probe check
File Utilities Displays folder, file, and USB flash drive options;
See File utilities for the USB flash drive on
page 110.
Options Rear USB Port (auto
detect, printer,
computer), printer
setup, GPIB setup, Set
date and time, error log
Update course
Autoset Enable Enable, Disable To further enhance the teaching process on
EDU oscilloscopes, you (the teacher) can
disable the Autoset function. For those
beginning labs where it is important for a student
to learn the basic operation of the scope,
disabling Autoset will help them apply their
knowledge of oscilloscope operation instead of
taking shortcuts with the Autoset button
Change Password
System Status Horizontal, vertical,
trigger, miscellaneous
Reference
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 107

Tektronix TBS1072B Specifications

General

Bandwidth	70 MHz
Channels	2
Sample Rate	1 GS/s
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Math Functions	Add, Subtract, Multiply, Divide, FFT
FFT	Yes
Input Coupling	AC, DC, GND
Record Length	2.5 k points
Display	7-inch WVGA (800 x 480) LCD
Trigger Modes	Edge, Pulse Width, Video
Automatic Measurements	Frequency, Period
Interfaces	USB 2.0
Rise Time	<= 5 ns
Input Impedance	1 MΩ ± 2%
Maximum Input Voltage	300 V (DC + peak AC)
Probe	1:1 and 10:1 passive probes included
Power Supply	100 to 240 V ±10%, 50/60 Hz
