Tektronix TBS1072B User Manual

Command entry
NOTE. For command information, refer to the TBS1000B, TDS2000C and
TPS2000 Series Digital Oscilloscopes Programmer Manual, 077-0444-XX. You
can download manuals at www.tektronix.com/manuals.
USB flash drive and device ports
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 71

Tektronix TBS1072B Specifications

General

Bandwidth	70 MHz
Channels	2
Sample Rate	1 GS/s
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Math Functions	Add, Subtract, Multiply, Divide, FFT
FFT	Yes
Input Coupling	AC, DC, GND
Record Length	2.5 k points
Display	7-inch WVGA (800 x 480) LCD
Trigger Modes	Edge, Pulse Width, Video
Automatic Measurements	Frequency, Period
Interfaces	USB 2.0
Rise Time	<= 5 ns
Input Impedance	1 MΩ ± 2%
Maximum Input Voltage	300 V (DC + peak AC)
Probe	1:1 and 10:1 passive probes included
Power Supply	100 to 240 V ±10%, 50/60 Hz
