Tenda AC9 User Manual

Specify Advanced Settings
46
current wireless network.
Transmit Power
There are three levels of signal strength for 2.4GHz and 5GHz frequency bands: low, medium, and
high (default). Select Low if it can satisfy you. Medium offers the widest coverage range while High
has strong capability of penetrating wall. Select one from them according to your needs.
WPS
WPS (Wi-Fi Protected Setup) allows you to join the WiFi network without typing the WiFi password.
You can establish a WPS connection to your wireless Router via WPS button, or PIN code.
To establish a WPS connection:
Log in to the Router’s User Interface, and click Wireless Settings > WPS.
Use a WPS button
If your wireless client has a WPS push button, you can use it to connect to the Router.
❶ Click the WPS button on the Webpage or press and hold the WPS button for about a second on
the Router and then release it.

Tenda AC9 Specifications

General

Color	black
Wi-Fi Speed	1167 megabits per second
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac, n
Gigabit Ethernet Speed	yes
Antennas	2
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa-psk, wpa2-psk
Ports	rj-45, usb
LAN Ports	4
WAN Ports	1
Built In Modem	yes

Weight and Dimensions

Height	3 inches
Width	8.9 inches
