Tenda O3 User Manual

75
5 Status
This module allows you to view the information of system and wireless network, including three
parts: system status, wireless status, and statistics.
5.1 System status
Log in to the web UI of the device, and choose Status. You can view the system status here.
If this device is set to AP mode, Client mode, Universal Repeater mode, Repeater mode or P2MP
mode, the system status is shown as follows. If the CPE has multiple Ethernet ports, this page
displays the current connection rate of each LAN port. OS3 is used for illustration.
If the device is set to WISP or Router mode, the system status is shown as follows:
When the CPE works in Router mode, the PoE port is changed to WAN port from LAN port.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
