Tenda O3 User Manual

86
6 Network
6.1 LAN setup
6.1.1 Overview
On the LAN Setup page, you can view the MAC address of the LAN port, configure the device
name, and type of obtaining an IP address and related parameters.
To access the page, choose Network > LAN Setup.
In AP, Client, Universal Repeater, Repeater, and P2MP modes, the page displays:
Parameters description
Name
Description
MAC Address
It specifies the MAC address of LAN port.
IP Address Type
It specifies the type of obtaining an IP address. The default is Static IP Address.

Static IP Address: Specify the IP address, subnet mask, default gateway, and DNS
server IP addresses manually.

DHCP (Dynamic IP Address): The device obtains an IP address, subnet mask,

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
