Thytronic NA11 User Manual

94
94
NA11 - Manual - 02 - 2009
MEASURES, LOGIC STATES AND COUNTERS
PT100 module Boot OK/NOT OK
PT100 module Run-time OK/NOT OK
Current loop module Boot OK/NOT OK
Current loop module Run-time OK/NOT OK
The diagnostic alarms can be allocated to an output relay; for this purpose the Self-test relay pa-
rameter can be set (K1...K6) inside the Set\Self-test Relay submenu.
Pilot wire diagnostic
Detailed diagnostic information about the pilot wire are available.
(Read\pilot wire diagnostic).
BLIN1 pilot wire breaking diagnostic state ON/OFF
Pilot wire BLIN1 shorted ON/OFF
Selective Block - Block2
The input and output state concerning the selective block are available (Read\Selective block-
BLOCK2).
Block2 input
Phase protections input selective block state BLK2IN-Iph ON/OFF
Ground protections input selective block state BLK2IN-IE ON/OFF
tB-Iph/IE Elapsed state tB timeout ON/OFF
Block2 output
Starting state of phase protections enabled
for external selective block on output ST-Iph-BLK2 ON/OFF
Starting state of ground protections enabled
for external selective block on output ST-IE-BLK2 ON/OFF
Phase protections output
selective block state BLK2-OUT-Iph ON/OFF
Ground protections
output selective block state BLK2-OUT-IE ON/OFF
Phase and ground protections
output selective block state BLK2-OUT-Iph/IE ON/OFF
Fault recording - SFR
Recording
[1]
is triggered by:
Relay activation (OFF-ON)
External trigger (binary input) programmed as Fault trigger
Element pickup
Twenty events are recorded into a circular FIFO (First In, First Out) buffer.
[2]
Following information are stored in every record:
Fault counter
[3]
Date and time
Fault cause
Phase currents I
L1r
, I
L2r
, I
L3r
Residual current I
Er
or I
ECr
Inputs
Outputs
Fault cause info (faulted phase)
Event recording - SER
Recording is triggered by:
Relay switching (OFF-ON or ON-OFF).
External trigger (binary input).
Setting change.
Three hundred events are recorded into a circular FIFO (First In, First Out) buffer.
[4]
Following information are stored in every record:
Event counter
[5]
Date and time
Event cause (binary input/output relay/setting changes)
Oscillography - DFR
Upon programmable trigger, the fault records are recorded in COMTRADE format; the sampled mea-
sures (24 sample per cycle) are stored in a circular shift memory buffer.
The fault record are self-triggered; they are stored in sequential order up the allocated memory is
used up after which the oldest memory is overwritten.
An operating procedure example for the digital fault recording is illustrated inside the ThySetter
section.
Note 1 Data concerning the twenty events are stored into non volatile memory; they are held in spite of power down
Note 2 Fault 0 is the newest event, while the Fault 19 is the oldest event
Note 3 Counter is updated at any new record; it may be cleared by means ThySetter
Note 4 Event 0 is the newest event, while the Event 299 is the oldest event
Note 5 Counter is updated at any new record; it may be cleared by means ThySetter
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
