Tornado 50 RV TB User Manual

38
TORNADO
USE AND MAINTENANCE MANUAL
428000393
237
EN
UPRIGHT DISPLAY CABINETS
C5 Electronic control board S1 Temperature probe I1 Cabinet switch U1 Compressor I2 Light switch U2 Condenser fan L1 Magnetic ballast U3 Evaporator fan L5 Fluorescent tube T8 U4 Cleaning fan R2 Drip defrosting heating resistor U8 Starter R3 Outside perimeter heating resistor R19 Drip tray heating resistor
Attachment 3 - WIRING DIAGRAM - 412100338000

Tornado 50 RV TB Specifications

General

Brand	Tornado
Model	50 RV TB
Category	Freezer
Language	English
