Tornado 50 RV TB User Manual

46
TORNADO
USE AND MAINTENANCE MANUAL
428000393
237
EN
UPRIGHT DISPLAY CABINETS
B2 Defrosting solenoid valve R7 Heating resistor glas C5 Electronic control S1 Temperature probe I1 Cabinet switch S2 Defrosting probe I2 Lighting switch T5 Transformer I6 Door microswitch U1 Compressor L1 Magnetic ballast U2 Condenser fan L5 Fluorescent tube T8 U3 Evaporator fan R2 Drip defrosting heating resistor U4 Cleaning fan R3 Outside perimeter heating resistor U8 Starter R6 Outside perimeter heating resistor
Attachment 11 - WIRING DIAGRAM - 412131616100

Tornado 50 RV TB Specifications

General

Brand	Tornado
Model	50 RV TB
Category	Freezer
Language	English
