Step
1
Installing the Wheels
Parts needed for this step:
4
Wheel assembly
Procedure
Note: T his procedure is only needed for Model
No . 07264TC .
1. R emo v e the fasteners securing the wheels .
2. R emo v e the shipping brac k et secured to the
wheel studs .
3. Mount the wheels with the previously remo v ed
fasteners ( Figure 3 ) and tor que to 45-65 ft-lb
(61-88 N ⋅ m).
Figure 3
1. Wheel assembly
3. Wheel stud (rear wheel hub
shown)
2. Wheel nut
Step
2
Installing the Steering
Wheel
Parts needed for this step:
1
Steering wheel
Procedure
Note: T his procedure is only needed for Model
No . 07264TC .
1. R emo v e the n ut and w asher from the steering
shaft.
2. Slide the steering wheel and w asher onto the
shaft. P osition the steering wheel on the shaft
so that the cross beam is horizontal when the
tires are pointed straight ahead and the thic k er
spok e of the steering wheel is do wnw ard.
3. Secure the steering wheel to the shaft with the
n ut ( Figure 4 ). T or que the n ut to 18-22 ft-lb
(24-29 N ⋅ m)
Figure 4
1. Steering wheel 3. Washer
2. Nut
4. Foam seal
