Figure 7
1. Hitch
Step
6
Installing the Cargo Box
Parts needed for this step:
1
Cargo box
1
Right-hand pivot bracket
1
Left-hand pivot bracket
4
Flange head screw (3/8 x 1 inch)
1
Bolt (5/16 x 3/4 inch)
1
Flange nut (5/16 inch)
Procedure
Note: T his procedure is only needed for Model
No . 07264TC .
1. P osition the carg o bo x onto the frame . T he
carg o bo x m ust la y flat and be centered.
2. Mount the left hand pi v ot brac k et to the left
rear cor ner of the frame with 2 flang e head
screws (3/8 x 1 inc h). P osition the brac k et as
sho wn in Figure 8 .
Figure 8
1. Pivot bracket
3. Slide the carg o bo x mounting hole onto the
pi v ot brac k et ( Figure 9 ).
Figure 9
1. Cargo box 3. Cargo box mounting hole
2. Pivot bracket
4. Inser t the right hand pi v ot brac k et into the
mounting hole in the carg o bo x and then
mount it to the frame .
5. Ha v e another person help to raise the carg o
bo x.
6. Loosen the bolt securing the prop rod clip to
the frame until y ou can slide the J-hook end of
the prop rod under the clip ( Figure 10 ).
14
