the time of man ufacture to allo w the booms to
be in this position for transit. Before operating
the mac hine , the springs m ust be adjusted to the
cor rect compression.
1. If necessar y , remo v e the pac king components
that secure the right and left extension booms
during shipping .
2. Suppor t the booms while they are extended
to the spra y position.
3. At the boom hing e , measure the compression
of the upper and lo w er springs while the booms
are in their extended position ( Figure 8 ).
A. All springs m ust be compressed until they
measure 1.56 inc hes .
B . Use the jam n ut to compress any spring
that measure g reater than 1.56 inc hes .
Figure 8
1. Boom hinge spring
2. Jam nut
4. R e peat the procedure for eac h spring on both
boom hing es .
5. Mo v e the booms into the transpor t “X”
position. See Operating the Booms in
Operation , pag e 25 for more infor mation.
Step
4
Completing the Setup:
Learning more about your
product.
Parts needed for this step:
1
Ignition key
1
Operator’s Manual
1
Engine Operator’s Manual
1
Parts Catalog
1
Operator Training Material
1
Registration Card
1
Pre-delivery Inspection Sheet
Procedure
1. R ead the man uals .
2. View the Operator training material.
3. Complete the registration card and retur n to
T oro .
4. Store the documentation in a safe place .
16
