Electrical System
Maintenance
Replacing the Fuses
T here are 2 fuse bloc ks and 1 empty slot in the
electrical system. T hey are located beneath the
seat ( Figure 55 ).
Figure 55
1. Left boom actuator thermal
breaker
6. Headlights
2. Right boom actuator
thermal breaker
7. Cruise control
3. Foam marker
8. Spray system
4. Open slot 9. Fuse blocks
5. Power
Servicing the Battery
Warning
CALIFORNIA
Pr oposition 65 W ar ning
Batter y posts, ter minals, and r elated
accessories contain lead and lead
compounds, chemicals kno wn to the State of
Calif or nia to cause cancer and r epr oducti v e
har m. W ash hands after handling .
Important: Do not jump star t the spray er .
Alw a ys k ee p the batter y clean and fully c harg ed.
Use a paper to w el to clean the batter y and batter y
bo x. If the batter y ter minals are cor roded, clean
them with a solution of four par ts w ater and one
par t baking soda. Apply a light coating of g rease
to the batter y ter minals to prev ent cor rosion.
V oltag e: 12 v olt with 280 cold cranking Amps @
0° F
Removing the Battery
1. P osition the spra yer on a lev el surface , set the
parking brak e , stop the pump , stop the engine ,
and remo v e the ignition k ey .
2. Loosen the knobs on the sides of the batter y
bo x and remo v e the batter y co v er ( Figure 56 ).
Figure 56
1. Knobs
3. Retainer
2. Battery
3. Disconnect the neg ati v e (blac k) g round cable
from the batter y post.
Incor r ect batter y ca ble r outing could
dama ge the spray er and ca bles causing
spar ks. Spar ks can cause the batter y
gasses to explode, r esulting in per sonal
injur y .
• Al w ays disconnect the negati v e
(black) batter y ca ble bef or e
disconnecting the positi v e (r ed)
ca ble.
• Al w ays r econnect the positi v e (r ed)
batter y ca ble bef or e r econnecting the
negati v e (black) ca ble.
49
