ProductOverview
Figure4
1.Sidedischargechute
7.Manualtube
2.Battery
8.Platform(downposition)
3.Engine9.Hydraulictank
4.Fueltank10.Mowerdeck
5.Controls
11.Frontcasterwheel
6.Motioncontrollevers
12.Operatorcushion
Controls
Becomefamiliarwithallthecontrols(Figure5)before
youstarttheengineandoperatethemachine.
g012564
1
7
2
8
3
9
4
10
5
11
6
12
Figure5
1.Fuelcap7.Hourmeter
2.Height-of-cutlever8.Choke
3.Bladecontrolswitch(PTO)
9.Ignitionswitch
4.Rightmotioncontrollever
10.Speedcontrollever
5.Leftmotioncontrollever
11.Fuelgauge
6.Parkingbrakelever12.Throttlecontrol
HourMeter
Thehourmeterrecordsthenumberofhourstheengine
hasoperated.Itoperateswhentheengineisrunning.
Usethesetimesforschedulingregularmaintenance
(
Figure6).
FuelGauge
Thefuelgaugeislocatedonthetop,middleofthetank
(Figure5).
SafetyInterlockIndicators
Therearesymbolsonthehourmeterandindicatewith
ablacktrianglethattheinterlockcomponentisinthe
correctposition(
Figure6).
BatteryIndicatorLight
IftheignitionkeyisturnedtotheOnpositionforafew
seconds,thebatteryvoltagewillbedisplayedinthearea
wherethehoursarenormallydisplayed.
Thebatterylightturnsonwhentheignitionisturned
onandwhenthechargeisbelowthecorrectoperating
level(Figure6).
