Toro GrandStand 74534TE User Manual

Figure66
1.Belt
3.Springloadedidlerpulley
2.Spring
ReplacingtheLeftMowerDeck
Belt
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Loosentheboltsandremovethebeltcoverswiththe
boltsattachedtothem.
4.Toremovetheleftmowerbelt,therightmowerbelt
needstoberemovedrst.RefertoReplacingthe
RightMowerBelt.
5.Removethespringfromtheanchorpostontheidler
pulleyarm(
Figure65).
6.Removethewornmowerbelt(
Figure65).
7.Installthenewmowerbeltaroundthedeckpulleys,
clutchpulleyandidlerpulley(Figure65).
8.Installthespringontotheanchorpost(
Figure65).
9.Installtherightmowerbelt.RefertoReplacingthe
RightMowerBelt.
10.Installthebeltcoversontothecuttingunitand
securethebolts.
Figure67
1.Belt
3.Spring
2.Springloadedidlerpulley
ReplacingthePumpDriveBelt
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Removethemowerdeckbeltfromtheclutchon
30inmowerdecksorremovetheleftmowerbelt
fromtheclutchfor40inmowerdecks.Referto
ReplacingtheMowerDeckBelts.
4.Tiltthemachineonit'sback.Referto
Pre-Maintenanceatthebeginningofthe
MaintenanceSection.
5.Unhooktheidlerspringfromtheframe(
Figure68).
6.Installthenewbeltaroundenginepumpdrivepulley
andthetwopumppulleys.
7.Installtheidlerspringtotheframe(
Figure68).
