Figure6
1.Safetyinterlocksymbols
3.Hourmeter
2.Batterylight
SpeedControlLever
Thismachinehasavariablespeedcontrol.Thiscontrols
howfastorslowthemachinewilltravelwiththemotion
controlleverspushedallthewayforward.
Note:Thenumbersnexttothespeedcontrolare
anapproximatemaximummilesperhour(mph)the
machinewilltravel.
ThrottleControl
ThethrottlecontrolisvariablebetweenFastandSlow.
Choke
Usethechoketostartacoldengine.
BladeControlSwitch(PTO)
Thebladecontrolswitch(PTO)isusedtoengage
theelectricclutchtodrivethemowerbladeswiththe
rightsidemotioncontrolleverinthecenter,un-locked
position.Pulltheswitchuptoengagethebladesand
release.Todisengagetheblades,pushthebladecontrol
switch(PTO)downormoveorreleasetherightside
motioncontrolleverintotheneutrallockposition.
IgnitionSwitch
Thisswitchisusedtostartthemowerengineandhas
threepositions:Off,RunandStart.
MotionControlLevers
Themotioncontrolleversareusedtodrivethemachine
forward,reverse,andturneitherdirection.
FuelShut-offValve
Closethefuelshut-offvalve(locatedbehindthe
operatorcushionontherighthandsideoffueltank)
whentransportingorstoringthemower.
Attachments/Accessories
AselectionofToroapprovedattachmentsand
accessoriesareavailableforusewiththemachineto
enhanceandexpanditscapabilities.Contactyour
AuthorizedServiceDealerorDistributororgoto
www.Toro.comforalistofallapprovedattachments
andaccessories.
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
Model74534TE
Widthwithdeectordown51.62inches(131.1cm)
Lengthwithplatformdown74inches(188cm)
Lengthwithplatformup61inches(155cm)
Height
48inches(121.9cm)
Weight
756(343kg)
Model74536TE
Widthwithdeectordown55.75inches(141.6cm)
Lengthwithplatformdown70inches(177.8cm)
Lengthwithplatformup57inches(144.8cm)
Height
48inches(121.9cm)
Weight
773(350.6kg)
15
