1
g012783
4 3 2
Figure89
1.10-1/8inch(25.7cm)for
102cmmowerdecksand
11-1/8inch(28.2cm)for
91cmmowerdecks
3.Frontnut
2.Springjamnut4.Compressionspring
ReplacingtheGrassDeector
WARNING
Anuncovereddischargeopeningcouldallowthe
lawnmowertothrowobjectsintheoperator'sor
bystander'sdirectionandresultinseriousinjury.
Also,contactwiththebladecouldoccur.
Neveroperatethelawnmowerunlessyouinstalla
coverplate,amulchplate,grassdeectororbagger.
1.Removethelocknut,bolt,springandspacerholding
thedeectortothepivotbrackets(
Figure90).
Removedamagedorworngrassdeector.
g015594
1
6 2
4
7
3
5
Figure90
1.Bolt
5.Springinstalled
2.Spacer6.GrassDeector
3.Locknut
7.Jhookendofspring
4.Spring
2.Placethespacerandspringontograssdeector.
PlaceoneJendofthespringbehindthedeckedge.
Note:MakesureoneJendofthespringisinstalled
behindthedeckedgebeforeinstallingtheboltas
shownin
Figure90.
3.Installtheboltandnut.PlaceoneJhookendofthe
springaroundthegrassdeector(Figure90).
Important:Thegrassdeectormustbeable
torotate.Liftthedeectoruptothefullopen
positionandensurethatitrotatesintothefull
downposition.
60
