2.Removethestrapsandbracessecuringthe
wingdecksforshipping.
2
LoweringtheFront-Deck
Winglets
Partsneededforthisprocedure:
1Rightdeckcover
1
Leftdeckcover
2V-belt
Procedure
1.Removethenutssecuringthefrontandrearstop
boltstotherightwinglet-deckmounts(Figure3).
g009013
Figure3
1.Winglet4.Eccentric
2.Hingepin5.Upperhole
3.Stopbolt
6.Deckmounts
2.Whilesupportingtherightwinglet,removethe
frontandrearstopboltsfromthedeckmounts
(Figure3).
Note:Leavetheeccentricspositionedbetween
thedeckmounts.
3.Lowerthewinglettotheoperatingposition.
4.Installthefrontandrearstopboltsthroughthe
upper-mountingholesandeccentrics(Figure4).
Note:Ensurethatthestopboltengagesthetab
onthehingepin.
g008868
Figure4
1.Winglet4.Eccentric
2.Hingepin5.Lowerhole
3.Bolt
5.Installthenutssecuringthestopbolts.
Note:Donottightenthenutsatthistime.
6.Repeatthisprocedureontheleftwinglet.
7.Installthewingletbeltsasfollows:
A.Startthebeltaroundthewinglet-spindle
pulleyandthefront-deck-spindlepulley
(Figure5).
g009155
Figure5
1.Winglet-spindlepulley3.Idlerpulley
2.Front-deck-spindlepulley
17
