B.Usingaratchetwrenchorasimilartool,
movetheidlerpulleyawayfromthepulleys
(Figure5).
C.Routethebeltaroundthewinglet-spindle
pulleyandtheupper-spindlepulleyonthe
frontdeck.
D.Releasetheidlerpulleytoputtensionon
thebelt.
8.Installthewinglet-deckcoverandsecureitwith
therubberlatch(Figure6).
Note:Ensurethatyouslidethecoverunderthe
front,centerdeck-covertabsbeforeinsertingit
ontothemountinghooksandpost.
9.Repeatthisprocedureontheotherwinglet.
g009156
Figure6
1.Cover
3.Front,centerdeck-cover
tabs
2.Rubberlatch4.Mounthooks
3
CheckingtheTireand
CasterWheelPressure
NoPartsRequired
Procedure
Checkthetireandcasterwheelpressurebeforeuse;
refertoCheckingtheTirePressure(page29)and
CheckingtheCasterWheelTirePressure(page29).
Important:Maintainpressureinalltiresto
ensureagoodquality-of-cutandpropermachine
performance.Donotunderinatethetires.
Important:Tractionperformance,including
tire-slipcontrol,isdependentontheratioofthe
tiresizebetweenthefrontandreartires.Useonly
genuineTorotires.
4
LevelingtheFront,Center
CuttingUnit
NoPartsRequired
Procedure
Note:Performthisprocedureonaat,levelsurface.
RefertoAdjustingtheHeightofCut(page30).
1.Rotatethebladeoneachouterspindleuntilthe
endsfaceforwardandbackward.
2.Measurefromtheoortothefronttipofthe
blade.
3.Adjustthe3mm(1/8inch)shimsonthefront
casterfork(s)tomatchthedesiredheightofcut.
4.Rotatetheblades180°andmeasurefromthe
oortotherear-facingtipoftheblade.
5.Loosenthelowerjamnutsontheheight-of-cut
chainU-bolt.
6.Adjustthenutstoraiseorlowertherearofthe
cuttingunitsothatthetipsoftherearblades
are6to10mm(1/4to3/8inch)higherthanthe
fronttips.
7.Tightenthejamnuts.
5
LevelingtheWingletDecks
totheFront,CenterCutting
Unit
NoPartsRequired
Procedure
1.Rotatethebladeoneachwingletsothatitpoints
sidetoside.
2.Loosentheboltsandnutssecuringthe2
eccentricspacerstothewinglets(Figure7).
18
