Figure 6
1. Full down position 2. Down position with bagger
installed
4. Install the tw o pins and secure them with the
hair pin cotter pins ( Figure 7 ).
Important: Ensur e that the r ear par t of
the seat is secur ed with the seat latch.
5. T o raise the roll bar , remo v e the hair pin cotter
pins and remo v e the tw o pins ( Figure 7 ).
6. Raise the roll bar to the upright position and
install the tw o pins and secure them with the
hair pin cotter pins ( Figure 7 ).
Important: Al w ays use the seat belt with
the r oll bar in the raised position.
Figure 7
1. Roll bar
3. Pin
2. Raised position
4. Hairpin cotter pin
Important: Tighten the fr ont knobs
a gainst the center r oll bar ends ( Figur e 5 ).
Think Safety First
Please read all safety instr uctions and symbols
in the safety section. Kno wing this infor mation
could help y ou or b ystanders a v oid injur y .
17
