Incor r ect batter y ca ble r outing could
dama ge the machine and ca bles causing
spar ks. Spar ks can cause the batter y gasses
to explode, r esulting in per sonal injur y .
• Al w ays Disconnect the negati v e (black)
batter y ca ble bef or e disconnecting the
positi v e (r ed) ca ble.
• Al w ays R econnect the positi v e (r ed)
batter y ca ble bef or e r econnecting the
negati v e (black) ca ble.
1. Diseng ag e the PTO , mo v e the motion control
lev ers to the neutral loc k ed position, and set
the parking brak e .
2. Stop the engine , remo v e the k ey , and w ait for
all mo ving par ts to stop before lea ving the
operating position.
3. Unlatc h the seat and tilt the seat up .
4. First disconnect the neg ati v e batter y cable
and g round wire from the neg ati v e (-) batter y
ter minal ( Figure 44 ).
5. Slide the red ter minal boot off the positi v e
(red) batter y ter minal. T hen remo v e the
positi v e (red) batter y cable ( Figure 44 ).
Figure 44
1. Battery
7. Washer (1/4 inch)
2. Terminal boot
8. Locknut (1/4 inch)
3. Positive battery cable 9. Battery clamp
4. Negative battery cable 10. J-bolts
5. Ground wire
11. Wingnut (1/4 inch)
6. Bolt (1/4 x 3/4 inch)
6. R emo v e both wing n uts (1/4 inc h) securing
the batter y clamp ( Figure 44 ).
7. R emo v e the batter y .
Installing the Battery
1. P osition batter y in the tra y with the ter minal
posts to w ard the engine ( Figure 44 ).
2. First, install the positi v e (red) batter y cable to
positi v e (+) batter y ter minal.
3. T hen install the neg ati v e batter y cable and
g round wire to the neg ati v e (-) batter y ter minal.
4. Secure the cables with 2 bolts (1/4 x 3/4 inc h),
2 w ashers (1/4 inc h), and 2 loc kn uts (1/4 inc h)
( Figure 44 ).
5. Slide the red ter minal boot onto the positi v e
(red) batter y post.
6. Secure batter y with J-bolts , hold do wn clamp
and 2 w ashers (1/4 inc h), and 2 wing n uts (1/4
inc h) ( Figure 44 ).
Charging the Battery
Charging the batter y pr oduces gasses that
can explode.
Nev er smok e near the batter y and k eep
spar ks and flames a w ay fr om batter y .
Important: Al w ays k eep the batter y
full y charged (1.265 specific g ra vity). T his
is especiall y impor tant to pr ev ent batter y
dama ge when the temperatur e is belo w 32°F
(0°C).
1. R emo v e the batter y from the c hassis .
2. Charg e batter y for 10 to 15 min utes at 25 to 30
amps or 30 min utes at 4-6 amps .
3. W hen the batter y is fully c harg ed, unplug
the c harg er from the electrical outlet, then
disconnect the c harg er leads from the batter y
posts ( Figure 45 ).
38
