Figure 45
4. Install the batter y in the mac hine and connect
the batter y cables; refer to Installing the
Batter y .
Note: Do not r un the mac hine with the
batter y disconnected, electrical damag e ma y
occur .
Servicing the Fuses
T he electrical system is protected b y fuses . It
requires no maintenance , ho w ev er , if a fuse blo ws
c hec k component/circuit for malfunction or shor t.
T he fuses are as follo ws:
• Main, 20 amp , blade-type
• Alter nator , 30 amp , blade-type
• F an, 30 amp , blade-type
1. Unlatc h the seat and raise the seat to g ain
access to fuse holder ( Figure 46 ).
Figure 46
1. Main F1-30 amp
2. Alternator F2-25 amp
2. T o re place the fuses , pull out on the fuse to
remo v e it.
3. Install a new fuse ( Figure 46 ).
39
